Specifications
Depth Camera Resolution: 2 Megapixels
Technology: Dual-camera Blue Structured Light
RGB Camera Resolution: 2 Megapixels
Single-frame Precision: Up to 0.02 mm
Outdoor Scanning: No
Single-frame Accuracy: Up to 0.05 mm
Color Scanning: Yes
Single Capture Area (at Nearest Distance): 52 x 64 mm at 120 mm
Scanner Weight: 175 g
Single Capture Area (at Furthest Distance): 168 x 132 mm at 250 mm
Dimensions (L x W x H): 132 x 53 x 36 mm
Working Distance: 120 ~ 250 mm
3D Printing Compatible : Yes
Point Distance: Up to 0.02 mm
Compatible Operating Systems: Window 10/11 (64-bit), Android, iOS, macOS
Minimum Scan Volume: 10 x 10 x 10 mm
White Flash LEDs: Yes
Scanning Speed: Up to 16 fps
CPU: 2 core, 1.8 GHz
Position Sensors: 9-axis IMU
Wi-Fi: Wi-Fi 6
Light Source: Class 1 Blue Light
Connector Type: USB Type-C
Tracking Methods: Feature/Marker
User Recalibration: Yes
Output File Formats: PLY, OBJ, STL, ASC, 3MF, GLTF, FBX
Special Object Scanning:Use scanning spray for transparent, dark, or highly reflective objects.
PC Requirements (macOS)
RAM: ≥8GB
CPU (or better):
M1 Pro/M1 Max/M1 Ultra
M2/M2 Pro/M2 Max/M2 Ultra
M3/M3 Pro/M3 Max
PC Requirements (Windows)
RAM: ≥16GB
CPU (or better):
i5 12th/13th/14th
i7 12th/13th/14th
i9 all series
1. Accuracy was acquired in a controlled lab environment. Actual results might vary, subject to the operation environment.
2. iOS devices only support Wi-Fi connection.
3. Class 1 Laser: Avoid direct eye exposure for extended periods! Refer to Standards for Class 1 Lasers for details.
4.Warning: This product has flashing lights which may not be suitable for people with photosensitive epilepsy.
